Switchgears

Assured Safety From Electrical Hazards

Engineered to deliver optimum security to the electrical appliances of your home and office, the Anchor UNO MCB range becomes a cherished partner of the premises. Powered by Panasonic technology, the range is designed by the finest brains of India and Japan.

These Circuit breakers secure the premises from electrical fire caused due to short circuits. Equipped with the exclusive mid-trip function makes it easy to identify circuit fault as knob stays in center in case of overload or short circuit. The high short circuit Breaking capacity of 10000A (10kA) makes it the perfect fit for your heavy electrical appliances.

Technical Specification:

Standard Conformity	IS/IEC 60898-1-2002
Standard Rated Current(In)	6A to 63A
Poles	SP, SP+N, DP, TP, TP+N, FP
Rated Short Circuit Breaking Capacity(Icn)	10000A(10kA)
Rated Voltage(Ue)	240/415 V AC
Rated Frequency(f)	50Hz
Rated Insulation Voltage(Ui)	660 V~
Ambient Temperature	-5 to 55oC
Contact indication	Red-ON & Green-OFF
Trip fault Indication	Mid Trip feature
Terminal Capacity	35sq mm
Energy Limiting Class	Class - 3
Watt Loss	As per the IS/IEC Standards
